9.4um F-theta 场镜点击次数：5374
发布时间：2020-06-27 |
|---|
| 9.4um | ||||||||
| 产品编号 | 镜片直径 | 焦距 | 扫描范围 | 入射光斑 | 工作距离 | 扫描角度 | 振镜间距 | 螺纹接口 |
| Part No | Lens Diameter (mm) | Focus Length (mm) | Scan Area (mm) | Input Beam (mm) | Work Distance (mm) | Max. Scan Angle (degree) | M1/M2 Separation (mm) | Thread |
| JG-SL1-9.4-75-50-12 | 48 | 75 | 50x50 | 12.00 | 75.9 | 25 | 16.00 | M85x1 |
| JG-SL1-9.4-100-70-12 | 48 | 100 | 70x70 | 12 | 107.4 | 25 | 16.00 | M85x1 |
| JG-SL1-9.4-150-110-12 | 48 | 150 | 110x110 | 12.00 | 152.7 | 25 | 16.00 | M85x1 |
| JG-SL1-9.4-200-140-12 | 48 | 200 | 140x140 | 12 | 204.3 | 25 | 16.00 | M85x1 |
| JG-SL1-9.4-250-175-12 | 48 | 250 | 175x175 | 12.00 | 256 | 25 | 16.00 | M85x1 |
| JG-SL1-9.4-300-210-12 | 48 | 300 | 210x210 | 12 | 308.6 | 25 | 16.00 | M85x1 |
| JG-SL1-9.4-350-250-12 | 48 | 350 | 250x250 | 12.00 | 369.2 | 25 | 16.00 | M85x1 |
| JG-SL1-9.4-430-300-12 | 48 | 430 | 300x300 | 12 | 444.0 | 25 | 16.00 | M85x1 |
| 9.4双片式 | |||||||
| 产品编号 | 焦距 | 扫描范围 | 入射光斑 | 工作距离 | 扫描角度 | 振镜间距 | 螺纹接口 |
| Part No | Focus Length (mm) | Scan Area (mm) | Input Beam (mm) | Work Distance (mm) | Max. Scan Angle (degree) | M1/M2 Separation (mm) | Thread |
| JG-SL2-9.4-100-70-10 | 100 | 70x70 | 10 | 107.4 | 25° | 12.56 | M85x1 |
| JG-SL2-9.4-100-70-20 | 100 | 70x70 | 20 | 108.5 | 25° | 25.25 | M85x1 |
| JG-SL2-9.4-150-110-14 | 150 | 110x110 | 14 | 152.7 | 25° | 16.42 | M85x1 |
| JG-SL2-9.4-200-140-14 | 200 | 140x140 | 14 | 204.3 | 25° | 16.42 | M85x1 |
| JG-SL2-9.4-220-140-20 | 220 | 140x140 | 20 | 250.0 | 25° | 25.25 | M85x1 |
| JG-SL2-9.4-250-175-14 | 250 | 175x175 | 14 | 256.0 | 25° | 16.42 | M85x1 |
| JG-SL2-9.4-300-210-14 | 300 | 210x210 | 14 | 308.6 | 25° | 16.42 | M85x1 |
| JG-SL2-9.4-300-210-20 | 320 | 210x210 | 20 | 352.0 | 25° | 25.25 | M85x1 |
| JG-SL2-9.4-350-250-14 | 350 | 250x250 | 14 | 369.2 | 25° | 16.42 | M85x1 |
| JG-SL2-9.4-480-310-20 | 480 | 310x310 | 20 | 530.0 | 25° | 25.25 | M85x1 |
